Storage Temp

LM062HWV02NS-DR01

LCD Shape

800*480

Backlight

250nits

Surface Luminance

6.2inch

LCD TYPE

TFT/TRANSMISSIVE

Viewing Direction

6 O'clock

LCM Interface

24BIT RGB

LCD Driver IC

ILI6123H+ILI5480

Price

Get Latest Price

这里可以自定义设置

DESCRIPTION

LM062HWV02NS-DR01 is a 6.2 inch TFT display with resistive touch.The model is featured with 24BIT RGB interface;This 6.2" TFT Touch Screen Module can be used in embedded systems, industrial device, security and hand-held equipment which require display in high quality and colorful image.

DRAWING

LCM Mechanical Diagram

SPECIFICATIONS

No.	Symbol	Description
1	AGND	Analog Ground
2	AVDD	Analog Power
3	DVDD	Digital Power
4~11	R0~R7	Data Input
12~19	G0~G7	Data Input
20~27	B0~B7	Data Input
28	DCLK	Clock input
29	DE	Data Enable signal
30	HSD	Horizontal sync input. Negative polarity
31	VSD	Vertical sync input. Negative polarity
32	MODE	DE/SYNC mode select .normally pull high H:DE mode. L: HSD/VSD mode
33	RSTB	Global reset pin. Active low to enter reset state. Suggest to connecting with an RC reset circuit for stability .normally pull high
34	STBYB	Standby mode, normally pull high STBYB="1",normal operation STBYB="0",timming control , soruce driver will turn off, all output are high-Z
35	SHLR	Source right or left sequence control.SHLR="L",shift left:last data=S1<- S2…S1200=first data SHLR="H",shift right:first data=S1->SS2…S1200=last data
35	SHLR
36	DVDD	Digital Power
37	UPDN	Gate up or down scan control. UPDN="L" , DOWN shift :G1->G2…->G480 ; UPDN="H", up shift: G1<-G2…<-G480
37	UPDN
38	GND	Digital Ground
39	AGND	Analog Ground
40	AVDD	Analog Power
41	VCOM	For external VCOM DC input (Adjustable)
42	DITH	Dithering setting: DITH="H" 6bit resolution (last 2 bits of input data truncated) (default setting) DITH="L" 8bit resolution
43~44	NC	No connection
45~54	V10~V1	Gamma correction voltage reference
55	NC	No connection
56	VDDG	Ground Power for TFT
57	DVDD	Digital Power
58	VEEG	Negative Power for TFT
59	GND	Digital Ground
60	NC	No connection

Item	Dimension	Unit
Size	6.2inch	inch
Dot Matrix	800RGB480(TFT)	dots
Module dimension	155.2X88.2X6.5	mm
Active area	137.52x77.23	mm
Dot pitch	0.135*0.135	mm
LCD type	TFT/TRANSMISSIVE
View Direction	12 O' CLOCK
Gray Scale Inversion Direction	6 O' CLOCK
Backlight Type	LED, Normally White
LCD Controller IC	ILI6123H+ILI5480
Pcap Controller IC
LCD Interface	24BIT RGB
Pcap Interface
Touch Panel
Surface	ANTI-GLARE
