G215HAN01.2 is a 21.5-inch a-Si TFT-LCD LCD module product launched by AUO. It is equipped with WLED backlight, no backlight driver, and no touch. The working temperature of this product is 0-60 ° C, the storage temperature is -20~60 ° C, and the vibration resistance is 1.5G (14.7 m/s ²). Its typical feature screen library is summarized as: white LED backlight, with a lifespan of over 50000 hours, inverted terminals, and a matte surface. Based on its feature screen library, this model is recommended for industrial and medical imaging applications. According to the intelligence obtained by the screen library, this product was mass-produced in Q2 2018 and is currently in mass production status. At present, this model has 17 spot information and 32 supplier information on the screen library, and is the main model product traded in the screen library market. The screen library first established parameters for this model on October 13, 2017, and finally updated the parameters on February 13, 2025. As an AHVA, normally black display, and transmissive LCD module product, G215HAN01.2 can provide a display brightness of 350 cd/m ² with a transmission contrast ratio of 1000:1, as well as a viewing angle of 89/89/89 (Typ.) (CR ≥ 10) (left/right/top/bottom). The optimal viewing angle is full view angle, and its response time is 12/10 (Typ.) (Tr/Td) ms. Due to the use of a 6-bit+Hi FRC grayscale signal for each pixel, this product can display 16.7M colors and achieve a color saturation of 72% (NTSC). In terms of backlight, this product uses a 12S4P WLED side entry light source (on the right) with a lifespan of 50K hours and does not include backlight drivers. G215HAN01.2 adopts LVDS (2 ch, 8-bit) signal interface, with a total of 30 pins, connected by terminals, and a screen driving voltage of 5.0V (Typ.). Its typical vertical refresh rate Fv is 60Hz.
