Wholesale 8.0 inch TFT IPS LCD Display Screen 1200 x 1920 Resolution With MIPI 4 Lanes

Model No
LM080PWX02NS
Resolution
800*1280
Brightness(cd/m²)
400
Sizes Range
8.0inch
Viewing Direction
All
LCM Interface
MIPI
LCD Driver IC
HX8260
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Captcha

Loading verification code...

Please complete verification first

这里可以自定义设置
No.SymbolDescription
1-3LED+Power supply for LED
4NCNo Connect
5-8LED-Power supply for LED
9-10GNDGround
11MIPI_2PMIPI data positive signal(2P)
12MIPI_2NMIPI data negative signal(2N)
13GNDGround
14MIPI_1PMIPI data positive signal(1P)
15MIPI_1NMIPI data negative signal(1N)
16GNDGround
17MIPI_CLKPMIPI data positive signal(CLKP)
18MIPI_CLKPMIPI data negative signal(CLKN)
19GNDGround
20MIPI_0PMIPI data positive signal(0P)
21MIPI_0NMIPI data negative signal(0N)
22GNDGround
23MIPI_3PMIPI data positive signal(3P)
24MIPI_3NMIPI data negative signal(3N)
25GNDGround
26VDDIOLogic power 1.8V
27RESETReset Pin
28GNDGround
29VDDIOLogic power 1.8V
30VDDLogic power 3.3V
31VDDLogic power 3.3V

Item

Symbol

Min

Typ

Max

Unit

Operating Temperature TOP-20
70
Storage TemperatureTST-30
70

Item

Symbol

Condition

Min

Typ

Max

Unit

Input PowerVDD
2.8 3.33.6V
Current for LED BacklightIf


140mA
