No. | Symbol | Common voltage |
1 | VCOM | Power Voltage for digital circuit |
2 | DVDD | Power Voltage for digital circuit |
3 | DVDD | No connection |
4 | NC | Global Reset Pin |
5 | RESET | Standby mode, Normally pulled high STBYB = “1”, normal operation STBYB= “0”, timing controller, source driver will turn off, all output are High-Z |
6 | STBYB | Power ground |
7 | GND | - LVDS differential data input |
8 | NIND0 | + LVDS differential data input |
9 | PIND0 | Power ground |
10 | GND | - LVDS differential data input |
11 | NIND1 | + LVDS differential data input |
12 | PIND1 | Power ground |
13 | GND | - LVDS differential data input |
14 | NIND2 | + LVDS differential data input |
15 | PIND2 | Power ground |
16 | GND | - LVDS differential data input |
17 | NINC | + LVDS differential data input |
18 | PINC | Power ground |
19 | GND | - LVDS differential data input |
20 | NIND3 | + LVDS differential data input |
21 | PIND3 | Power ground |
22 | GND | No connection |
23 | NC | No connection |
24 | NC | Power ground |
25 | GND | No connection |
26 | NC | No connection |
27 | NC | 6bit/8bit mode select |
28 | SELB | Power for Analog Circuit |
29 | AVDD | Power ground |
34 | UPDN | Vertical inversion |
35 | VGL | Gate OFF Voltage |
36 | NC | No connection |
37 | NC | No connection |
38 | VGH | Gate ON Voltage |
39 | LED+ | LED Anode |
40 | LED+ | LED Anode |
Item | Symbol | Min | Typ | Max | Unit | |
Operating Temperature | TOP | -20 | 70 | ℃ | ||
Storage Temperature | TST | -30 | 80 | ℃ |
Item | Symbol | Condition | Min | Typ | Max | Unit |
Input Power | VDD | 2.5 | 3.3 | 6 | V | |
Current for LED Backlight | IL | 80 | mA |
