The LMT028QV022C-DR007 is a 2.8-inch TFT LCD module designed for embedded systems requiring a reliable, compact display solution with touch functionality. Featuring a 240×320 resolution and an 8-bit parallel 80-series interface, this module delivers crisp color graphics with fast data transfer suitable for microcontroller-based applications. The built-in resistive touch panel (RTP) enables intuitive user interaction, while its wide operating temperature range ensures stable performance in diverse environments.
| Parameter | Value |
|---|---|
| Display Size | 2.8 inch diagonal |
| Resolution | 240 × RGB × 320 pixels |
| LCD Type | TFT Transmissive |
| Interface | 8-Bit Parallel (80 series) |
| Touch Panel | Resistive Touch Panel (RTP) |
| Viewing Direction | 12 O'clock |
| Active Area | 43.2 × 57.45 mm |
| Outline Dimension | 50.0 × 98.5 × 3.6 mm |
| Brightness | 300 cd/m² (typical) |
| Backlight Type | White LED |
| Operating Temperature | -20°C ~ +70°C |
| Storage Temperature | -30°C ~ +80°C |
| OEM/ODM | Supported |
The 2.8-inch TFT panel delivers vivid, full-color visuals with 240×320 pixel resolution, making it ideal for user interfaces, data monitoring, and portable device displays. The transmissive LCD technology paired with a bright white LED backlight (300 cd/m²) ensures clear visibility in various lighting conditions .
The integrated 4-wire resistive touch screen provides reliable touch input detection, capable of registering presses from fingers or stylus. Resistive touch technology allows operation even when wearing gloves, making this module suitable for industrial and outdoor applications .
The 80-series 8-bit parallel interface enables high-speed data transfer, delivering smooth graphical performance with minimal latency. This interface is compatible with a wide range of MCUs and development platforms, including Arduino and various ARM-based controllers . For projects requiring reduced pin count, alternative SPI or RGB interfaces may be considered for similar display modules .
Engineered for reliability, the module operates across a wide temperature range of -20°C to +70°C and can be stored between -30°C and +80°C . This makes it suitable for demanding applications in industrial control, automotive systems, outdoor equipment, and handheld devices.
With an outline dimension of 50.0 × 98.5 × 3.6 mm and an active area of 43.2 × 57.45 mm, the module offers a space-efficient design that integrates easily into portable and space-constrained products. The 12 O'clock optimal viewing direction ensures consistent image quality in portrait orientation.
Customization options are available for cover glass shape, FPC cable length and interface definition, touch panel selection (resistive/capacitive), communication interface types, and surface optical treatments (anti-glare, anti-reflection, anti-fingerprint) . All products comply with RoHS environmental standards.
Industrial Control Panels – HMI interfaces for machinery and equipment
Handheld Instruments – Portable measurement and testing devices
Medical Equipment – Diagnostic displays and patient monitors
Home Appliances – Smart control interfaces
IoT Devices – Interactive data terminals
Laboratory Equipment – Analytical instrument displays
Embedded Systems – Custom microcontroller-based projects
| Model | LMT028QV022C-DR007 |
|---|---|
| Touch Panel | Resistive (RTP) included |
| Interface | 8-Bit Parallel 80 series |
| Resolution | 240 × 320 |
| Status | Active |
