      LCD Mall workable tft lcd panel custom out-door application

      Storage Temp
      LM057CV01HS
      LCD Shape
      5.7inch
      Backlight
      700
      Surface Luminance
      5.7inch
      Viewing Direction
      6 O'CLOCK
      LCM Interface
      18-BIT RGB
      LCD Driver IC
      HX8250-A01*2+HX8678A
      Price
      Get Latest Price
      Get the latest price
      Quantity Needed：
      Pieces
      E-mail：
      Captcha

      Loading verification code...

      Please complete verification first

      这里可以自定义设置
      More
      More
      Pin No.SymbolDescription
      1U/DUp/down scan setting.
      When U/D=H, reverse scan.
      When U/D=L, normal scan
      2NCNo connection
      3HSYNCHorizontal sync input in digital RGB and CCIR601 mode.
      (Short to GND if not used)
      4~6VLEDPower supply for BLU LDO circuit
      7VCCPower supply
      8VSYNCVertical sync input in digital RGB and CCIR601 mode.
      (Short to GND if not used)
      9DEInput data enable control. When DE mode, active High to enable data input.
      Default pull low
      10NC(X2)No connection.(Touch panel control PIN: X2)
      11NC(Y1)No connection.(Touch panel control PIN: Y1)
      12ADJChip Enable (Active High)
      13~15B5~B3Blue data input
      16VSSPower ground.
      17~19B2~B0Blue data input
      20VSSPower ground.
      21~23G5~G3Green data input
      24VSSPower ground.
      25~27G2~G0Green data input
      28VSSPower ground.
      29~31R5~R3Red data input
      32VSSPower ground.
      33~35R2~R0Red data input
      36NC(X1)No connection.(Touch panel control PIN: X1)
      37NC(Y2)No connection.(Touch panel control PIN: Y2)
      38DCLKClock signal. Latching data at the rising edge
      39VSSPower ground
      40L/RThe shift direction of device internal shift register is controlled by this pin
      as shown below:
      L/R=H: STH->SO1->• • •->SO960->STHO
      L/R=L: STH->SO960->• • •->SO1->STHO

      Item

      Symbol

      Min

      Typ

      Max

      Unit

      Operating Temperature TOP-20
      		70℃
      Storage TemperatureTST-30
      		80℃

      Item

      Symbol

      Condition

      Min

      Typ

      Max

      Unit

      Input PowerVCC
      		2.7 3.33.6V
      Current for LED BacklightIL


      		140mA
