1.69'' Passive Matrix OLED display

1.69'' Passive Matrix OLED display

Model No
LM0169WQQ01NN
Resolution
128x128 RGB
Brightness(cd/m²)
16-bit color/ High contrast : 2000:1
Sizes Range
1.69
Touch surface
26.86 (W) x 26.86 (H)
Power supply
3.3V / 5V
LCD TYPE
Passive Matrix OLED
LCM OD sizes
33.8 (W) x 43.7 (H) x 1.41 (T)
Viewing Direction
>160°
LCM Interface
8-bit 6800-series Parallel Interface, 8-bit 8080-series Parallel Interface, Serial Peripheral Interface, I 2 C Interface.
LCD Driver IC
SSD1327
LCM Power supply
3.3V / 5V
