      oem oled display panel free delivery for smartphones

      Storage Temp
      LM055NFH01NN
      LCD Shape
      1080*1920
      Backlight
      350nits
      Size (inch)
      CST148
      LCD TYPE
      AM OLED display
      LCM OD sizes
      5.5inch
      Viewing Direction
      All viewing
      LCM Interface
      MIPI 4LANE
      LCD Driver IC
      RM67198
      Price
      Get Latest Price
      Get the latest price
      Quantity Needed：
      Pieces
      E-mail：
      Captcha

      Loading verification code...

      Please complete verification first

      这里可以自定义设置

      DESCRIPTION



      LM055NFH01NN is a 5.5 inch AMOLED Display. The model is featured with MIPI 4LANE interface; with on-cell touch, LCD Mall can design coverglass as per your needing; Contrast ratio min 10,000, with 350nits brightness achieve perfect view. This 5.5inch OLED's response time less than 1ms. Apply to smart handhold, smart Pos machine, support outdoor application.

      DRAWING

      LCM Mechanical Diagram

      More
      More

      Item

      Dimension

      Unit

      Size5.5inch
      Dot Matrix1080*RGB*1920dots
      Module dimension31.4*42.9*3.05mm
      Active area68.256(W)×121.344 (H)mm
      Dot pitch94.8 (W)×63.2(H)um
      LCD typeTFT/TRANSMISSIVE
      View DirectionAll Viewing
      Backlight TypeNo
      LCD Controller ICRM67198
      Pcap Controller ICCST148
      LCD InterfaceMIPI 4LANE
      Pcap InterfaceI2C
      Touch PanelOn Cell
      SurfaceGLARE

      Item

      Symbol

      Min

      Typ

      Max

      Unit

      Operating Temperature TOP-20
      		60℃
      Storage TemperatureTST-30
      		70℃

      Item

      Symbol

      Condition

      Min

      Typ

      Max

      Unit

      Logic Power supplyVDDIO
      		1.651.83.3
      Analog Power supplyVCI
      		2.652.83.6
      Power IC Power SupplyVBAT
      		2.93.74.5
