| No. | Symbol | Description |
| 1 | GND | Ground |
| 2 | AVDD | Power for Analog Circuit |
| 3 | VCC | Power Voltage for digital circuit |
| 4-11 | R0~R7 | Red data |
| 12-19 | G0~G7 | Green data |
| 20-27 | B0~B7 | Blue data |
| 28 | CLKIN | Sample clock |
| 29 | DEN | Display enable PIN form controller |
| 30 | HSD | Horizontal sunc input |
| 31 | VCD | Vertical sync input |
| 32 | MODE | DE/SYNC mode select |
| 33-35 | NC | No connect |
| 36 | VCC | Power Voltage for digital circuit |
| 37 | NC | No connect |
| 38 | GND | Ground |
| 39 | GND | Ground |
| 40 | AVDD | Power for Analog Circuit |
| 41 | VCOM | Common voltage |
| 42 | DITH | Dithering function |
| 43 | NC | No connect |
| 44 | VCOM OUT | Common voltage |
| 45-55 | NC | No connect |
| 56 | VGH | Gate ON Voltage |
| 57 | VCC | Power Voltage for digital circuit |
| 58 | VGL | Gate OFF Voltage |
| 59 | GND | Ground |
| 60 | NC | No connect |
Item | Symbol | Min | Typ | Max | Unit | |
| Operating Temperature | TOP | -20 | 70 | ℃ | ||
| Storage Temperature | TST | -30 | 80 | ℃ | ||
Item | Symbol | Condition | Min | Typ | Max | Unit |
| Supply Voltage For LCM | VDD | 3.0 | 3.3 | 3.6 | V | |
| Current for LED Backlight | IL | 240 | mA |
