Home  >  PRODUCT  >  TFT Touchscreen  >  6.2

6.2

Model No
LM062HWV02NS-DR01
Resolution
800*480
Brightness(cd/m²)
250nits
Sizes Range
6.2inch
LCD TYPE
TFT/TRANSMISSIVE
Viewing Direction
6 O'clock
LCM Interface
24BIT RGB
LCD Driver IC
ILI6123H+ILI5480
Price
Get Latest Price
Get the latest price
Quantity Needed:
Pieces
E-mail:
Captcha

Loading verification code...

Please complete verification first

这里可以自定义设置
No.SymbolDescription
1AGNDAnalog Ground
2AVDDAnalog Power
3DVDDDigital Power
4~11R0~R7Data Input
12~19G0~G7Data Input
20~27B0~B7Data Input
28DCLKClock input
29DEData Enable signal
30HSDHorizontal sync input. Negative polarity
31VSDVertical sync input. Negative polarity
32MODEDE/SYNC mode select .normally pull high H:DE mode. L: HSD/VSD mode
33RSTBGlobal reset pin. Active low to enter reset state. Suggest to connecting with an RC reset circuit for stability .normally pull high
34STBYBStandby mode, normally pull high STBYB="1",normal operation STBYB="0",timming control , soruce driver will turn off, all output are high-Z
35SHLRSource right or left sequence control.SHLR="L",shift left:last data=S1<- S2…S1200=first data SHLR="H",shift right:first data=S1->SS2…S1200=last data
36DVDDDigital Power
37UPDNGate up or down scan control. UPDN="L" , DOWN shift :G1->G2…->G480 ; UPDN="H", up shift: G1<-G2…<-G480
38GNDDigital Ground
39AGNDAnalog Ground
40AVDDAnalog Power
41VCOMFor external VCOM DC input (Adjustable)
42DITHDithering setting: DITH="H" 6bit resolution (last 2 bits of input data truncated) (default setting) DITH="L" 8bit resolution
43~44NCNo connection
45~54V10~V1Gamma correction voltage reference
55NCNo connection
56VDDGGround Power for TFT
57DVDDDigital Power
58VEEGNegative Power for TFT
59GNDDigital Ground
60NCNo connection

Item

Dimension

Unit

Size6.2inchinch
Dot Matrix800*RGB*480(TFT)dots
Module dimension155.2X88.2X6.5mm
Active area137.52x77.23mm
Dot pitch0.135*0.135mm
LCD typeTFT/TRANSMISSIVE
View Direction12 O' CLOCK
Gray Scale Inversion Direction6 O' CLOCK
Backlight TypeLED, Normally White
LCD Controller ICILI6123H+ILI5480
Pcap Controller IC
LCD Interface24BIT RGB
Pcap Interface
Touch Panel
SurfaceANTI-GLARE

Item

Symbol

Min

Typ

Max

Unit

Operating Temperature TOP-10
60
Storage TemperatureTST-20
70

Item

Symbol

Condition

Min

Typ

Max

Unit

Input PowerVCC
3.0 3.33.6V
Supply current (One LED)ILED

120
mA
