| No. | Symbol | Description |
| 1 | AGND | Analog Ground |
| 2 | AVDD | Analog Power |
| 3 | DVDD | Digital Power |
| 4~11 | R0~R7 | Data Input |
| 12~19 | G0~G7 | Data Input |
| 20~27 | B0~B7 | Data Input |
| 28 | DCLK | Clock input |
| 29 | DE | Data Enable signal |
| 30 | HSD | Horizontal sync input. Negative polarity |
| 31 | VSD | Vertical sync input. Negative polarity |
| 32 | MODE | DE/SYNC mode select .normally pull high H:DE mode. L: HSD/VSD mode |
| 33 | RSTB | Global reset pin. Active low to enter reset state. Suggest to connecting with an RC reset circuit for stability .normally pull high |
| 34 | STBYB | Standby mode, normally pull high STBYB="1",normal operation STBYB="0",timming control , soruce driver will turn off, all output are high-Z |
| 35 | SHLR | Source right or left sequence control.SHLR="L",shift left:last data=S1<- S2…S1200=first data SHLR="H",shift right:first data=S1->SS2…S1200=last data |
| 36 | DVDD | Digital Power |
| 37 | UPDN | Gate up or down scan control. UPDN="L" , DOWN shift :G1->G2…->G480 ; UPDN="H", up shift: G1<-G2…<-G480 |
| 38 | GND | Digital Ground |
| 39 | AGND | Analog Ground |
| 40 | AVDD | Analog Power |
| 41 | VCOM | For external VCOM DC input (Adjustable) |
| 42 | DITH | Dithering setting: DITH="H" 6bit resolution (last 2 bits of input data truncated) (default setting) DITH="L" 8bit resolution |
| 43~44 | NC | No connection |
| 45~54 | V10~V1 | Gamma correction voltage reference |
| 55 | NC | No connection |
| 56 | VDDG | Ground Power for TFT |
| 57 | DVDD | Digital Power |
| 58 | VEEG | Negative Power for TFT |
| 59 | GND | Digital Ground |
| 60 | NC | No connection |
Item | Dimension | Unit | ||||||
| Size | 6.2inch | inch | ||||||
| Dot Matrix | 800*RGB*480(TFT) | dots | ||||||
| Module dimension | 155.2X88.2X6.5 | mm | ||||||
| Active area | 137.52x77.23 | mm | ||||||
| Dot pitch | 0.135*0.135 | mm | ||||||
| LCD type | TFT/TRANSMISSIVE | |||||||
| View Direction | 12 O' CLOCK | |||||||
| Gray Scale Inversion Direction | 6 O' CLOCK | |||||||
| Backlight Type | LED, Normally White | |||||||
| LCD Controller IC | ILI6123H+ILI5480 | |||||||
| Pcap Controller IC | ||||||||
| LCD Interface | 24BIT RGB | |||||||
| Pcap Interface | ||||||||
| Touch Panel | ||||||||
| Surface | ANTI-GLARE | |||||||
Item | Symbol | Min | Typ | Max | Unit | |
| Operating Temperature | TOP | -10 | 60 | ℃ | ||
| Storage Temperature | TST | -20 | 70 | ℃ | ||
Item | Symbol | Condition | Min | Typ | Max | Unit |
| Input Power | VCC | 3.0 | 3.3 | 3.6 | V | |
| Supply current (One LED) | ILED | 120 | mA |
