| No. | Symbol | Common voltage |
| 1 | VCOM | Power Voltage for digital circuit |
| 2 | DVDD | Power Voltage for digital circuit |
| 3 | DVDD | No connection |
| 4 | NC | Global Reset Pin |
| 5 | RESET | Standby mode, Normally pulled high STBYB = “1”, normal operation STBYB= “0”, timing controller, source driver will turn off, all output are High-Z |
| 6 | STBYB | Power ground |
| 7 | GND | - LVDS differential data input |
| 8 | NIND0 | + LVDS differential data input |
| 9 | PIND0 | Power ground |
| 10 | GND | - LVDS differential data input |
| 11 | NIND1 | + LVDS differential data input |
| 12 | PIND1 | Power ground |
| 13 | GND | - LVDS differential data input |
| 14 | NIND2 | + LVDS differential data input |
| 15 | PIND2 | Power ground |
| 16 | GND | - LVDS differential data input |
| 17 | NINC | + LVDS differential data input |
| 18 | PINC | Power ground |
| 19 | GND | - LVDS differential data input |
| 20 | NIND3 | + LVDS differential data input |
| 21 | PIND3 | Power ground |
| 22 | GND | No connection |
| 23 | NC | No connection |
| 24 | NC | Power ground |
| 25 | GND | No connection |
| 26 | NC | No connection |
| 27 | NC | 6bit/8bit mode select |
| 28 | SELB | Power for Analog Circuit |
| 29 | AVDD | Power ground |
| 34 | UPDN | Vertical inversion |
| 35 | VGL | Gate OFF Voltage |
| 36 | NC | No connection |
| 37 | NC | No connection |
| 38 | VGH | Gate ON Voltage |
| 39 | LED+ | LED Anode |
| 40 | LED+ | LED Anode |
Item  | Symbol  | Min  | Typ  | Max  | Unit  | |
| Operating Temperature | TOP | -20 | 70 | ℃ | ||
| Storage Temperature | TST | -30 | 80 | ℃ | ||
Item  | Symbol  | Condition  | Min  | Typ  | Max  | Unit  |
| Input Power | VDD | 2.5 | 3.3 | 6 | V | |
| Current for LED Backlight | IL | 80 | mA |
